Delrin® Product Sheet
Delrin® Renewable Attributed RA511CPE
Product overview
Delrin® Renewable Attributed (RA) 511CPE—a nucleated medium
viscosity, low emission acetal homopolymer—supports your
sustainability goals with:
• Base polymer produced from 100% certified bio-feedstock from
waste, accredited through the International Sustainability and
Carbon Certification (ISCC) mass balance certification system
• Bio-feedstock from second-generation sources, not in
competition with the food and feed chain
• 100% certified renewable electricity used for production
Delrin used in e-bikes
• Lower product cradle-to-gate carbon footprint
Delrin® RA511CPE delivers state-of-the-art low VOC
technology and top-class mechanical properties with reduced
lifecycle greenhouse gas emissions and lower fossil resource use.
• Reduction of non-renewable fossil resource usage
• Low VOC (below 2 ppm in VDA 275)
Delrin® RA511CPE offers the same superior performance and
quality as Delrin® 511CPE with an improved environmental
impact profile. (Sustainability assessment conducted using a
cradle-to-gate Life Cycle Assessment (LCA) in accordance with
ISO 14040/14044 methodology)
Properties*
Test method
Unit
Delrin® Delrin®
511CPE RA511CPE
Melt mass-flow rate (MFR 190°C, 2.16kg) g/10min
ISO 1133
Mold shrinkage (parallel/normal)
%
ISO 294-4
1.8/1.8
Density
g/cm
ISO 1183
1.42
Melting temperature, 10°C/min
°C
Notched Charpy at 23°C
ISO 11357-1/-3
kJ/m
ISO 179/1eA
Notched Charpy at -30°C
kJ/m
ISO 179/1eA
6.5
Tensile strength at yield
MPa
ISO 527-1/-2
Yield strain
%
ISO 527-1/-2
Nominal strain at break
%
ISO 527-1/-2
Tensile modulus
MPa
ISO 527-1/-2
Flexural modulus
MPa
ISO 178
*Information in this table is based on technical data that Delrin believes to be reliable and represents typical
values that relate only to the specific material designated. This information may be subject to revision as new
knowledge and experience becomes available.
Source: DuPont
Tensile modulus
Melt
mass-flow
rate
Optimize your resource efficiency
Yield
strain
The use of reground Delrin has almost no influence on
mechanical properties and molding performance. Five passes with
100% reground material are possible without any negative effect
on mechanical properties. Using Delrin helps increase your internal
recycling rate and achieves substantial environmental and
financial savings.
Reliable parts, made to last
Notched
charpy
impact
strength
(23°C)
Yield
stress
By optimizing part design, Delrin® Renewable Attributed enables
environmental and cost savings compared to medium MW
copolymer alternatives.
Notched charpy
impact strength (-30°C)
Delrin® RA511CPE
Delrin® RA511CPE
In addition to the ability to make durable parts at possibly higher
production rates, when you work with Delrin you can count on
consistent quality and supply stability. Plus, our design, technical
and processing support helps you produce high-quality parts that
deliver on their promise.
Typical MMW Copolymer
Typical MMW Copolymer
Typical HMW Copolymer
Typical HMW Copolymer
Source: DuPont
High performance
Delrin® Renewable Attributed RA511CPE outperforms both
medium and high molecular weight (MW) acetal copolymers,
enabling sustainable design.
Certified sustainability
Potentially
-18%
part weight
Potentially
-23%
hold pressure
time
CO2e per part
reduction
Cost
reduction
Delrin® RA511CPE base polymer is produced using 100% biofeedstock from waste, in accordance with mass balance principles.
A mass balance approach and chain of custody utilizes separate
bookkeeping from cradle to gate (feedstock to finished product)
and enables supply chain traceability. The Delrin Renewable
Attributed manufacturing site and supply chain are accredited
through the globally-recognized International Sustainability and
Carbon Certification (ISCC) certification system.
Enable sustainable design
Delrin® RA511CPE delivers superior performance compared to
competitive medium MW copolymers, as well as competitive high
MW copolymers. With higher tensile properties (+20%) and
increased impact resistance (+15%) achieved on a significantly
better flow, Delrin® RA511CPE permits the design of parts with thinner
walls while maintaining full functionality.
Designing lighter parts with Delrin® RA511CPE saves energy,
resources and money.
To learn more, contact your Delrin representative or visit Delrin.com.
